The platform works in harmony with the motor, driving the rear wheel, and turning power into speed.

• Ultra light Hollow Core carbon frame
• Avinox M2S drive unit and long-range 800Wh battery across all build levels
• Available in XS to XL frame sizes
• Full-color, OLED touchscreen display
• Wireless Avinox remotes
• 160mm travel fork
• 150mm of progressive rear suspension travel
• Mixed-wheel setup
• Geo flip chip via upper link mount
• Full internal routing with Pivot Cable Port System
• Injection molded rubberized frame protection
• Pivot dock tool system compatible
• Water bottle clearance on all sizes

Build Specs

Fork: Rockshox Zeb Ultimate 29", 44mm offset, 160mm

Rear Shock: Rockshox Super Deluxe Ultimate

Headset: Pivot Precision Sealed Cartridge

Rear Derailleur: SRAM XO Eagle Transmission 12-speed

Cassette: SRAM GX 1275 Eagle Transmission 10-52t

Shifter: SRAM AXS Pod Controller

Brakes: SRAM Maven Silver 4-Piston

Crankset: Praxis Alloy eCranks E-MTB 34t-155mm

Handlebar: Phoenix Team Carbon 35mm Rise

Grips: Phoenix Factory Lock-On

Stem: Phoenix Team Enduro 50mm

Seatpost: One-Up Dropper V3 180mm

Saddle: Pivot Pro E-Bike

Drive Unit: Avinox M2S 800wh

Wheels: DT Swiss Hybrid HX1501, 30mm - Mixed 15x110 F/12x157 R

Tires: Continental Kyrptotal-F 29" x 2.4" Super Soft Compound Enduro Casing Kyrptotal-R 27.5" x 2.6 Soft Compound Enduro Casing

Rotors: SRAM HS2 6-Bolt - 200mm SRAM HS2 6 Bolt - 200mm

Chain: SRAM XO Eagle Flattop 12-speed

**Specs may change without notice
