Modern MTB Design
Tapered fork steerer tubes*, quality components including a 1x drivetrain* with clutch-equipped rear derailleurs, thru-axle hubs*, internal cable routing (including dropper seatpost) and an integrated chainstay protector give aspiring trail riders room to grow. *on select models
Off-Road Control
New geometry is optimized for confident trail riding and two different wheel sizes (27.5 or 29-inch) depending on frame size. The geometry is also designed for front suspension with either an 80mm or 100mm fork depending on frame size. All models have clearance for high-volume tires (up to 2.4-inch) for traction and grip on technical terrain.
Light and Durable
All-new ALUXX aluminum frame features updated shaping and a lighter overall weight for improved performance on off-road terrain.
-
Frame
ALUXX-grade aluminum, disc
-
Fork
SR Suntour XCE, QR, steel steerer XS: 80mm travel (27.5) S: 80mm travel (27.5) / 100mm travel (29) M:100mm travel (29) L: 100mm travel (29) XL: 100mm travel (29) XXL: 100mm travel (29)
-
Shock
N/A
-
Handlebar
Giant Connect Trail, 31.8mm XS: 690mm (27.5) S: 690mm (27.5) / 750mm (29) M: 780mm (29) L: 780mm (29) XL: 780mm (29) XXL: 780mm (29)
-
Grips
Giant Sole-O
-
Stem
Giant Sport, 7-degree XS: 40mm (27.5) S: 50mm (27.5) / 50mm (29) M: 60mm (29) L: 70mm (29) XL: 80mm (29) XXL: 90mm (29)
-
Seatpost
Giant Sport, 30.9 XS: 350mm (27.5) S: 350mm (27.5) / 375mm (29) M: 375mm (29) L: 375mm (29) XL: 420mm (29) XXL: 420mm (29)
-
Saddle
Giant ErgoContact Trail
-
Pedals
MTB caged
-
Shifters
microSHIFT Acolyte, 1x8
-
Front Derailleur
N/A
-
Rear Derailleur
microSHIFT Acolyte, clutch
-
Brakes
Tektro 172, mechanical, Tektro rotors [F]160mm, [R]160mm
-
Brake Levers
Tektro TBK 172, mechanical
-
Cassette
microSHIFT, 12x46
-
Chain
KMC 8.1
-
Crankset
ProWheel Forged, 32t (27.5) or 30t (29) XS: 165mm (27.5) S: 165mm (27.5) / 170mm (29) M: 175mm (29) L: 170mm (29) XL: 175mm (29) XXL: 175mm (29)
-
Bottom Bracket
cartridge
-
Rims
Giant GX03V 29 or 27.5, alloy, double wall, 21mm inner width
-
Hubs
[F] QR alloy, sealed bearing, [R] Giant Tracker hub, 12x142 thru axle, 24-pawl drive
-
Spokes
stainless, 14g
-
Tires
Maxxis Ikon 27.5x2.2 or Maxxis Ikon 29x2.2, wire bead
-
Extras
2.4" max tire size
