Yeti Cycles SB140 T1

Yeti Cycles SB140 T1
$7,900.00
Color:
Turquoise
Options:
DT Swiss XM 1700 Aluminum Wheelset
Size:
Medium
Please select options

Details

Some say the SB140 never met a dirt it didn't like. We agree in spades. What's your pleasure? Drag a bar. Make an edit. Stay out after dark. Try it. Land it. Or just stay at it. Happy to pedal. Greedy for more. The mayor of jibtown, proudly wearing the rip crown. The SB140. Down to fun.

Geometry Chart:
SIZEX-SMALLSMALLMEDIUMLARGEX-LARGE
A SEAT TUBE LENGTH (mm) 355 380 410 450 495
B TOPTUBE LENGTH (mm) 536.9 565.8 597.2 620.1 648.1
C HEADTUBE ANGLE 65.5 65.4 65.4 65.4 65.4
D EFF. SEAT TUBE ANGLE 77.6 77.5 77.5 77.4 77.3
E CHAINSTAY LENGTH (mm) 432.9 432.9 432.9 432.9 432.9
F WHEELBASE (mm) 1140.2 1171.3 1203.6 1228.3 1257.9
G ESTIMATED BB HEIGHT (mm) 336.6 336.6 336.7 336.8 336.9
H STANDOVER (mm) 698.4 703.8 706.2 708.6 711
I HEADTUBE LENGTH (mm) 95.5 109.9 115.4 126.4 137.5
J AXLE TO CROWN (mm) 539.1 539.1 539.1 539.1 539.1
K OFFSET (mm) 37 37 37 37 37
L STACK (mm) 578.8 591.7 596.5 606.4 616.3
M REACH (mm) 409.6 434.6 464.5 484.5 509.5
N FRONT CENTER (mm) 707.3 738.4 770.7 795.4 825
Sizes:
X-Small 149 cm - 160 cm
Small 155 cm - 170 cm
Medium 165 cm - 180 cm
Large 178 cm - 191 cm
X-Large 185 cm - 201 cm

Specs

Frame TURQ Series carbon fiber frame, Switch Infinity suspension technology, press-fit BB92, internally tunneled cable routing, 148mm x 12mm BOOST dropouts, sealed enduro max pivot bearings, integrated derailleur hanger, and axle.
Fork FOX FACTORY 36 FIT 4/150MM
Rear Shock FOX FACTORY FLOAT DPS
Wheels Select from dropdown above
Tires Front: MAXXIS MINION DHF 2.6 EXO
Rear: MAXXIS REKON 2.6 EXO
Bottom Bracket SHIMANO XT BB92
Crankset SHIMANO XT 30T 170MM
Shifters SHIMANO XT
Rear Derailleur SHIMANO XT
Cassette/Freewheel SHIMANO XT 10-51
Chain SHIMANO XT
Brakes SHIMANO XT 4 PISTON
Rotors SHIMANO 180/SHIMANO 180
Handlebars YETI CARBON 35X760MM
Tape/Grips ODI ELITE PRO
Stem RACE FACE AEFFECT R 35X50
Headset CANE CREEK 40 INTEGRATED
Seatpost FOX TRANSFER 31.6MM / SM: 125MM, MD: 150MM, LG/XL: 175MM
Saddle SILVERADO CUSTOM

* Subject to change without notice.

Part Numbers

Option MPN Store SKU
Turquoise / DT Swiss XM 1700 Aluminum Wheelset / Medium B22140TMDPTUFAT016500 210000023029
